Sewage Treatment Plant of Automatic Dosing Machine for Polymer Dissolving Unit
● Specially suitable for both dry powder and liquid flocculant (optional);
c.The flocculant dissolving concentration are available in certain scope;
● Heating device is equipped to prevent condensation which may cause by thedamp powder;
● Auto intermittent agitating function,which make sure the solution can be mixedthroughly and keep the solution in good condition(HPL3 series);
● Auto alarming and stopping when the powder feeding hopper at low stock,which have the advantage of energy-saving (optional);
● Low noise-low vibration and stable performance;
● Material adopts stainless steel sus304(standard type), others please confirm with us before ordering;
● Top brand spare parts to ensure excellent performance;
● Auto powder feeding vacuum auxiliary system (optional)
Technical Parameters
| Model | Type | Capacity(Lt/hr) | Powder hopper capacity (L) | Powder screw conveyor motor(HP) | Agitating motor(HP) | Tank material | |
| Stand | Optional | ||||||
| HPL2-500 | Two tanks continuous type | 500 | 55 | 1/4 | 1/2*2 | SUS304 | SUS316PP PVC FRP |
| HPL2-1000 | 1000 | 55 | 1/4 | 3/4*2 | |||
| HPL2-1500 | 1500 | 55 | 1/4 | 1*2 | |||
| HPL2-2000 | 2000 | 110 | 1/4 | 1*2 | |||
| HPL3-500 | Three tanks continuous type | 500 | 55 | 1/4 | 1/4*3 | SUS304 |
SUS316PP PVC FRP |
| HPL3-1000 | 1000 | 55 | 1/4 | 1/4*3 | |||
| HPL3-1500 | 1500 | 55 | 1/4 | 1/2*3 | |||
| HPL3-2000 | 2000 | 110 | 1/4 | 1/2*3 | |||
| HPL3-3000 | 3000 | 110 | 1/4 | 1*3 | |||
| HPL3-4000 | 4000 | 110 | 1/4 | 1*3 | |||
| HPL3-5000 | 5000 | 200 | 1/4 | 2*3 | |||
| HPL3-8000 | 8000 | 350 | 1/4 | 2*3 | |||
Product Description
STRUCTURE DIAGRAM WITH HPL2
Standard Equipements
1. Tanks made of SUS304
2. Powder Feeding Hopper
3. Heater
4. Water in-feed pipeline control package *1set
5. Chemical solution agitator *2sets
6. Control panel(installed on amchine)
7. Level sensor
8. Operation/Maintenance manual*1pc
9. Warrantee of machine
Optional Equipment
1. Powder level sensor
2. Auto powder Feeding System
3. Water Feeding Pump
4. Chemical Solution Feeding Pump
5. High Consistency Solution/dissolving System diluting
STRUCTURE DIAGRAM WITH HPL3
Standard Equipements
1. Tanks made of SUS304
2. Powder Feeding Hopper
3. Heater
4. Water in-feed pipeline control package *1set
5. Chemical solution agitator *2sets
6. Control panel(installed on amchine)
7. Level sensor
8. Mixer
9. LED Rotation Speed DisHPLay
10. Operation/Maintenance manual*1pc
11. Warrantee of machine
Optional Equipment
1. Powder level sensor
2. Auto powder Feeding System
3. PL.C. Control Panel
4. Water Feeding Pump
5. Chemical Solution Feeding Pump
6. High Consistency Solution/dissolving System diluting
Packing & Delivery
Material preparation corner
FAQ
Food & beverage processing (CIP cleaning, disinfection)
Power plants (boiler water treatment)
Oil & gas (scale/corrosion inhibitors)
Pharmaceuticals (precise chemical mixing).
