Product details of the membrane disc diffuser

Quick Overview

DUBHE membrane disc diffuser features reasonable structure and appealing design. The product has been tested for a long time and thus has a stable performance. DUBHE has been cooperating with lots of professional manufacturers in China.

Product Information

Compared with other ordinary products, the membrane disc diffuser produced by Dubhe has the following advantages.

Product details

A-7

A-3

A-5

Material

EPDM

PTFE

EPDM diaphragm performance parameters

Item	Criteria	Unit	Values
Hardness	ASTM D2240-95	Shore A	60
Tensile strength	ASTM D412-92	N/mm²	>2000
Tear strength	ASTMD624-91,Die T	N/m	>110
Permanent deformation at 100% elongation	ASTM D412-92	%	<5%
Maximum elongation at tear	ASTM-D412-92	%	600
Ozone Resistance (70hours, 40°C, 50mPa partial ozone pressure, no decomposition)	ASTM D1171-94	-	eligible (voter etc)
UV resistance	-	-	Qualified
Hot air ageing resistance (70hours, 70°C)	ASTM D573-88	-	Tear strength change rate <3%
		-	Change in tearing elongation <25%
		-	Hardness change <5 degrees
Rate of change of deformation in compression (22hours, 70°C)	ASTM D573-88	%	<20
Liquid Resistance, Volume Change (water, 70hours, 100°C)	ASTM D471-94	%	<3
Low Temperature Resistance (-40º C, non-crisp)	ASTM D832-92	-	Qualified

Attached: Membrane material composition table
Polymer	58%
Carbon Black	17.5%
Plasticisers	19%
Others	5.5%

PTFE test report

SSI PTFE and PEEK coated diffusion films do not contain PFAS or PFOA.

When SSI worked with suppliers to develop coatings in the 2000s, SSI insisted on coating packages that did not contain heavy metals or by-products that could theoretically be used in potable water service, even if our products were used in wastewater.

Drawings & Dimensions

C-5 (2)

C-6 (2)

C-7 (2)

Applications

COMPANY STRENGTH

In a wastewater treatment plant, the Fine Bubble Disc Diffuser is installed in the aeration tank, where it releases a constant stream of small air bubbles. These bubbles rise to the surface, creating turbulence and increasing the contact between air and water. This allows for the transfer of oxygen from the air into the water, promoting the growth of beneficial bacteria that break down organic matter.

COMPANY STRENGTH

In an aquaculture facility, the Fine Bubble Disc Diffuser is used to provide oxygen to fish and other aquatic animals. The small bubbles created by the diffuser help to increase the dissolved oxygen levels in the water, creating a healthier environment for the aquatic life to thrive in.

In industrial processes, the Fine Bubble Disc Diffuser is used to aerate and mix liquids, such as in fermentation tanks or chemical reactors. It helps to improve the efficiency of the process by providing a constant supply of oxygen and promoting mixing and circulation.

COMPANY STRENGTH

Overall, the Fine Bubble Disc Diffuser is a versatile and essential product that plays a crucial role in various applications. Its high-quality design and efficient performance make it a popular choice for aeration systems around the world.

Company Advantages

DUBHE is a well-developed mature company that produces membrane disc diffuser. membrane disc diffuser has won high recognition from customers with its highest quality. We protect the environment through the eco-friendly design and manufacturing of our products and solutions, and the adoption of sustainable measures in our services and supply chain operations.
Our products are of high quality and great safety. Besides, they are packed tightly and shockproof. Customers can rest assured to purchase our products and are warmly welcomed to contact us for details.
