Static Screen Wastewater Treatment by DUBHE

Technical Data & External Dimensions

Inlet and outlet sizes can be adjusted according to customer's water requirements.

Static Screen Specification
Model	Slot（mm）	TS-300	TS-500	TS-600	TS-700	TS-800	TS-900	TS-1000	TS-1200	TS-1500	TS-1800	TS-2000
Treating capacity (m³/hr)	0.2	2	3	4	4.5	5	6	7	8.5	10	12	13
	0.5	5	8	10	12	13.5	15	16.5	20	20	30	33
	1	10	17	20	24	27	30	33	40	50	60	67
	1.5	19	32	38	44	51	57	63	76	95	114	127
	2	25	42	50	58	67	75	83	100	125	150	167
Dimensions (mm)	L	1440	1440	1440	1440	1440	1440	1440	1440	1440	1440	1440
	W	430	630	730	830	930	1030	1130	1330	1630	1930	2130
	H	1840	1840	1840	1840	1840	1840	1840	1840	1840	1840	1840
Water inlet	DIN	DN50	DN100	DN100	DN100	DN100	DN150	DN150	DN200	DN200	DN200	DN200
Water outlet		DN50	DN100	DN100	DN100	DN100	DN150	DN150	DN200	DN200	DN200	DN200
Net weight	kg	204	234	248	263	278	362	279	419	470	543	592

B-1 (12)

B-2 (16)

Product details

A-3 (28)

A-4 (25)

A-1 (29)

Company Advantages

· static screen wastewater treatment follows the 'simple and reliable, and environmental protection' design concept.

· DUBHE conducts strict quality management system and the quality of this product is assured.

· The product is appropriate for various applications and is more widely used by people from various fields.

Company Features

· Shanghai Dubhe Environmental Protection Technology Co.,Ltd is a well-respected company that produces a full range static screen wastewater treatment.

· Shanghai Dubhe Environmental Protection Technology Co.,Ltd uses a unique production process and production technology.

· Shanghai Dubhe Environmental Protection Technology Co.,Ltd aims to become a top-notch static screen wastewater treatment brand with international influence. Get quote!

Application of the Product

Our static screen wastewater treatment meets the needs of multiple industries and fields.

With many years of practical experience, Dubhe is capable of providing comprehensive and efficient one-stop solutions.
